Structural category
Plane installation type
Outward appearance code
LMF55
LM36
LM42
LM48
Outward appearance illustration
Overall dimensions
Flush
Detection distance
DC
6~
36
VDC
NPN
NO
NC
NO+NC
PNP
NO
NC
NO+NC
two wire
system
﹛
NO
NC
AC
90~
250
VAC
SCR
Control-
lable
silicon
NO
NC
NO+NC
﹛
Relay output
﹛
﹛
﹛
﹛
N0n-flush
Detection distance
25mm
15mm
20mm
20mm
25mm
DC
6~
36
VDC
NPN
NO
LMF55-3025NA
LM36-3015NA
LM42-3020NA
LM48-3020NA
LM55-3025NA
NC
LMF55-3025NB
LM36-3015NB
LM42-3020NB
LM48-3020NB
LM55-3025NB
NO+NC
LMF55-3025NC
LM36-3015NC
LM42-3020NC
LM48-3020NC
LM55-3025NC
PNP
NO
LMF55-3025PA
LM36-3015PA
LM42-3020PA
LM48-3020PA
LM55-3025PA
NC
LMF55-3025PB
LM36-3015PB
LM42-3020PB
LM48-3020PB
LM55-3025PB
NO+NC
LMF55-3025PC
LM36-3015PC
LM42-3020PC
LM48-3020PC
LM55-3025PC
two wire
system
﹛
NO
LM36-3015LA
LM42-3020LA
LM48-3020LA
LM55-3025LA
NC
LM36-2015LB
LM42-3020LB
LM48-3020LB
LM55-3025LB
AC
90~
250
VAC
SCR
Control-
lable
silicon
NO
LMF55-2025A
LM36-2015A
LM42-2020A
LM48-2020A
LM55-2025A
NC
LMF55-2025B
LM36-2015B
LM42-2020B
LM48-2020B
LM55-2025B
NO+NC
LMF55-2025C
﹛
﹛
LM48-2020C
LM55-2025C
Relay output
LMF55-2025JC
﹛
﹛
﹛
﹛
Control
output
DC
300mA
300mA
300mA
300mA
300mA
SCR Relay
﹛
500mA/2A
500mA
500mA/2A
500mA
500mA
Output voltage dropDC/AC
DC < 3V﹜AC < 10V
Consumption current
DC < 3V﹜AC < 10V
Standard detected object
70℅70℅1(A3 iron)
45℅45℅1(A3 iron)
25℅25℅1(A3 iron)
60℅60℅1(A3 iron)
55℅55℅1(A3 iron)
Repeated precision
0.05
0.02
0.01
0.05
0.05
DC/AC Response frequency
200Hz/25Hz
200Hz/20Hz
200Hz/25Hz
200Hz/10Hz
200Hz/10Hz
Working environment temperature
-25⊥ ~+75⊥
-25⊥ ~+75⊥
-25⊥ ~+75⊥
-25⊥ ~+75⊥
-25⊥ ~+75⊥
Insulation resistance
50M次
50M次
50M次
50M次
50M次
Shell material
ABS Resin
ABS Resin
ABS Resin
ABS Resin
ABS Resin
Protection grade
IP67
IP67
IP67
IP67
IP67
Alternative model at home and abroad
SD-↓↓
SE-↓↓
