Structural category
Cylinder type
Angular column type
Outward appearance code
LM480
LMF1
LMF2
LMF3
Outward appearance illustration
Overall dimensions
Flush
Detection distance
5mm
5mm
5mm
DC
6~
36
VDC
NPN
NO
LMF1-3005NA
LMF2-3005NA
LMF3-3005NA
NC
LMF1-3005NB
LMF2-3005NB
LMF3-3005NB
NO+NC
PNP
NO
LMF1-3005PA
LMF2-3005PA
LMF3-3005PA
NC
LMF1-3005PB
LMF2-3005PB
LMF3-3005PB
NO+NC
two wire
system
NO
LMF1-3005LA
LMF2-3005LA
LMF3-3005LA
NC
LMF1-3005LB
LMF2-3005LB
LMF3-3005LB
AC
90~
250
VAC
SCR
Control-
lable
silicon
NO
NC
NO+NC
Relay output
N0n-flush
Detection distance
25mm
DC
6~
36
VDC
NPN
NO
LM480-3025NA
NC
LM480-3025NB
NO+NC
LM480-3025NC
PNP
NO
LM480-3025PA
NC
LM480-3025PB
NO+NC
LM480-3025PC
two wire
system
NO
NC
AC
90~
250
VAC
SCR
Control-
lable
silicon
NO
LM480-3025A
LMF1-2005A
LMF2-2005A
LMF3-2005A
NC
LM480-3025B
LMF1-2005B
LMF3-2005B
NO+NC
LM480-3025C
Relay output
Control
output
DC
200mA
SCR Relay
300mA
Output voltage dropDC/AC
DC < 3V、AC < 10V
Consumption current
DC < 15mA、AC < 10mA
Standard detected object
50〜50〜1(A3 iron)
20〜20〜1(A3 iron)
Repeated precision
0.1
0.02
DC/AC Response frequency
100Hz/25Hz 400Hz/25Hz
Working environment temperature
-25≧ ~+75≧
Insulation resistance
50MΩ
Shell material
Metal
ABS Resin
Protection grade
IP67
IP67
Alternative model at home and abroad
SFE-＆＆
SN04-N
TL-Q5MC1
PS17-＆
