Product Introduction:
1.Adhesive Lined Heat Shrinkable Tube for Automotive Oil Pipe protection is specially designed to protect
the automotive oil pipe from librations and frictions during operation, and greatly improve the safety of automotives;
2.Shrink temperature:120℃;
3.Operating temperature:-55℃ ~ 125℃;
4.RoHS compliant.

Standard color:

Black(Other color available upon request.)

Technical Data:

Property

Test Method

Standard

Tensile Strength

ASTM D2671

≥12MPa

Elongation

ASTM D2671

≥300%

Longitudinal shrinkage

UL 224

≤±10%

Operating Temperature

IEC 216

-55℃～+105℃

Flexibility under low Temperature

ASTM D746

No Cracking at-35℃

Specification:

Size
(mm)

As Supplied

After Recovery(mm)

 Application Range

Standard Package
(m/spool)

I.D.(mm)

Min.
W.T.(mm)

Thickness of
Adhesive
Layer(mm)

I.D.(mm)

inch

mm

GPFS-Φ5.0

≥5.0

1.0

0.3±0.1

≤4.6

1/8

3.5

200

GPFS-Φ6.0

≥6.0

1.0

0.3±0.1

≤6.0

3/16

4.76

200

GPFS-Φ8.0

≥8.0

1.0

0.3±0.1

≤7.0

1/4

6.35

100

GPFS-Φ11.0

≥11.0

1.1

0.3±0.1

≤3.3

5/16

8.0

100

GPFS-Φ15.0

≥15.0

1.2

0.3±0.1

≤7.0

3/8

10.0

100
