THD -- fixation with lid for conduits

Material: PA6
Temperature range: -30 up to +100

standard colour: Black and grey

Standard system: UL  CE  VDE  CSA  CCC
Features:
One piece design( hinged lid construction)
Openable when installed in line
Snap-fie lid and central screw-hole allow easy fixation

Type

For conduit

Hole dia.

Height

Width

Packet units

Article NO.
grey

Article NO.
black

THD AD10.0

AD10.0

4.2

26.70

21.70

50

0601.010.109

0601.010.209

THD AD13.0

AD13.0

4.2

32.00

26.00

50

0601.013.109

0601.013.209

THD AD15.8

AD15.8

4.2

32.00

26.00

50

0601.015.109

0601.015.209

THD AD18.5

AD18.5

4.2

40.00

32.50

50

0601.018.109

0601.018.209

THD AD21.2

AD21.2

4.2

40.00

23.50

50

0601.021.109

0601.021.209

THD AD28.5

AD28.5

4.2

43.40

43.40

20

0601.028.109

0601.028.209

THD AD34.5

AD34.5

4.2

53.40

43.40

20

0601.034.109

0601.034.209

THD AD42.5

AD42.5

4.2

80.00

65.00

10

0601.042.109

0601.042.209

THD AD54.5

AD54.5

4.2

80.00

65.00

5

0601.054.109

0601.054.209

THC  Open fixation for conduit

Material: PA6
Temperature range: -30 up to +100

Standard colours: Black and grey

Standard system: UL  CE  VDE  CSA  CCC
Features:

Type

For conduit

Hole dia.

Height

Width

Packet units

Article NO.
grey

Article NO.
black

THC AD10.0

AD10.0

4

23

30

50

0603.010.109

0603.010.209

THC AD13.0

AD13.0

4

23

30

50

0603.013.109

0603.013.209

THC AD15.8

AD15.8

4

23

30

50

0603.015.109

0603.015.209

THC AD18.5

AD18.5

5

30

35

50

0603.018.109

0603.018.209

THC AD21.2

AD21.2

5

30

35

50

0603.021.109

0603.021.209

THC AD28.5

AD28.5

6

38

42

20

0603.028.109

0603.028.209

THC AD34.5

AD34.5

6

43

51

20

0603.034.109

0603.034.209

THC AD42.5

AD42.5

6

51

61

10

0603.042.109

0603.042.209

THC AD54.5

AD54.5

6

64

74

5

0603.054.109

0603.054.209
